One-Stop OEM Assembly Printed Circuit Board/PCBA with RoHS

Productivity:
100000 Pieces Per Month
Place of Origin:
Guangdong, China (Mainland)
Supply Ability:
100000 Pieces Per Month

Basic Info

Model No.:  pcb001

Product Description

Model NO.: pcb001 Base Material: Cem-1, Kb Raw Material Board Thickness: 1.6mm-2.0mm Min. Line Width: 0.3mm Color: Green/Blue/White Assembly Capability: SMT& DIP Trademark: Xuhai Specification: 202*115MM HS Code: 8534009000 Dielectric: CEM-1 Copper Thickness: 1.0 Oz; 2.0 Oz Min. Hole Size: 1mm Welding Template: 235-250degree Board Type: Rigid, Flexible, Rigid-Flex Certificate: ISO, RoHS Transport Package: Box Packaging(50cm*32cm*32cm) Origin: Guangdong, China (Mainland)  High quality multilayer printed circuit board PCB

PCB Assembly SMT & DIP manufacturing Capabilities:
Type of Assembly    SMT, Thru-hole, Cable assembly, Wire Harness
Max. PCB Size 202*115MM
Solder Type Water Soluble Solder, Lead-Free, Wave soldering
Package Anti-static Bubble Bag & Carton



Components

BGA and VFBGA
Leadless Chip Carriers/CSP/QFN
Double-sided SMT Assembly
Fine Pitch to 0.8mils
BGA Repair and Reball
Part Removal and Replacement
PCB assembly process IQC for incoming materials checking----Material baking----SMT----- Semi-Products Testing & QC ---DIP parts -- IPQC--- Wave Soldering--Semi-Products Testing & QC-----Assembling-----ICT or Xray-----100% Function Testing-----Reliability Testing (burn-testing) - Package - Shipping

Thank you for choosing XUHAI!

Delivery Detail:3-7 days after confirming the order for pcba




Details:
which offers complete solutions for materials sourcing & procurement, PCBA (Printed Circuit Board Assembly), box building (plastic or metal enclosure), manufacturing and order shipment etc.


One-Stop OEM Assembly Printed Circuit Board/PCBA with RoHS





One-Stop OEM Assembly Printed Circuit Board/PCBA with RoHS

OEM & ODM Orders are Welcome.
We have in-house workshop for one stop shop service
OEM (We manufacture according to your design - BOM, Gerber file and testing procedures, while providing you best recommendations for easy manufacturing and cost saving):
1. Component sourcing and procurement
2. PCB Manufacturing
3. Component Assembly (PCBA - SMT & Through Hole parts)
4. Chip-on-board (COB)
Surface-mount technology (SMT)
Ball-grid array (BGA)
Through-hole
5. Plastic Enclosure (Mould) Manufacturing
6. Metal Enclosure (Tool) Manufacturing
7. Cable & Wire harness Assembly
8. Final Assembly
9. QC Testing
10.Packaging
One-Stop OEM Assembly Printed Circuit Board/PCBA with RoHS

One-Stop OEM Assembly Printed Circuit Board/PCBA with RoHS


One-Stop OEM Assembly Printed Circuit Board/PCBA with RoHS
We sincerely hope to establish longtime and friendly business relationship with you. If you have interest in our product, please don't hesitate to contact us !

Contact us if you need more details on PCB/PCBA. We are ready to answer your questions on packaging, logistics, certification or any other aspects about PCB Board、Electronics. If these products fail to match your need, please contact us and we would like to provide relevant information.
