High Quality 0.1 K 63 Film Capacitor

Basic Info

Model No.:  capacitor

Product Description

Model NO.: Capacitor Application: General Purpose Capacitance: 50-100uf Manufacturing Material: Polyester Usage: High Frequency Coupling Filter: Liquid Tantalum Capacitor Rated Voltage: 50V~1200V Color: Green Application of Capacitor: All Kinds of Electronic Life-Time: 1000-4000hours Insulation Resistance: 3000s Transport Package: Box Packaging(50cm*32cm*32cm) Origin: Guangdong, China (Mainland) Type: Polyester Film Capacitor Packaging Type: Through Hole Structure: Variable Capacitor Electrolyte: Air Medium Tuning: Polystyrene Capacitor Operating Temperature: -55°c~+105°c Tolerance: ±20% Certificate: RoHS/ISO9000 Reference Standard: GB6346(IEC60384-11) Shipping by: FedEx DHL TNT UPS Trademark: Xuhai Specification: Custom Size Polyester film metal foil capacitor-inductive (Dipped):
  ◊Features: •Polyester film and foil,inductive winding construction. •Leads wire are solder on AL,small size. •Epoxy resin vacuum-dipped.
  ◊Typical applications: •Widely used in Dc and low pulse circuits. •Widely used in high temperture light(up 105°c).
  Product Description

Reference standard

GB 6346(IEC 60384-11)

Climate category

50/100/21

Rated temperature range

85ºC

Operating temperature range



-55ºC-105ºC(+85ºC to +105ºC decreasing factor 1.25% per ºC for VR(dc))

Rated voltage

50V.63V/100V.160V/250V.400V.630V.1000V/1200V

Capacitance range

0.001μF-0.47μF

Capacitance tolerance

±5%(J), ±10%(K), ±20%(M)

Voltage proof

2.0UR(5s)

Dissipation factor

Frequency

Dissipation factor

1KHZ

<1.0% 20ºC

10KH

<1.5% 20ºC

Insulation resistance

CR≤0.1μF, IR≥30000MΩ

CR>0.1μF, IR≥10000MΩ

20ºC,100V,60S


 Rated voltage

Code

A

B

C

D

E

F

G

H

J

1

10

12.5

16

20

25

/

/

50

63

2

100

125

/

200

250

/

400

500

630

3

1000

/

1600

2000

2500

3150

4000

5000

6300

Ps.3T refers to special voltage 1200V, 3Y refers to 1800V.
Nominal capacitance

Code

101

471

332

472

103

473

104

474

nominal capacitance

100PF

470PF

3.3nF

4.7nF

0.01uF

0.047uF

0.1uF

0.47uF

Ps. Nominal capacity using three digits, said the unit for PF, its significance as the first and second digits as valid number, the third. The number of two digits behind zero before said
Tolerance of nominal capacitance

code

G

J

K

tolerance of nominal capacitance

±2.0%

±5.0%

±10%


High Quality 0.1 K 63 Film Capacitor

High Quality 0.1 K 63 Film Capacitor

Contact us if you need more details on Plyester Capacitor. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Capacitor、Green Polyester Film Capacitor. If these products fail to match your need, please contact us and we would like to provide relevant information.
