Fuse Clip for 5 X 20 mm Tube Fuse

    Payment Type: T/T, Western Union
    Min. Order: 1000
    Place of Origin:  Shanghai, China
  • Mr. Catherine Zhou

Basic Info

Model No.:  JZ-002

Product Description

Model NO.: JZ-002 Trademark: songshan Origin: Shanghai, China Usaga: Low Voltage Specification: 5× 20 mm HS Code: 85361000 JZ-002 Fuse Clip is fitted with 5.0 x 20 mm tube Fuse. The product appearance is in the shape of corner and main material of the product is tin phosphor bronze, thus it has good contact. The clamping force of the clip can reach more than 2N. It applies to the fuse with rated current 6A or below. It is used on users' supporting circuit board. The thickness of the material is 3u, there is no deformation in case of long-term use, and the versatility is also great. Thanks to the high-tech coating the material uses, the fuse clip is durable, antioxidant, no color fading. The product maintains a consistent quality level and there is no reduction in raw materials. The product has been exported to overseas and has great praise!

Fuse Clips
A=Model              B=For Fuse-Links
C= Current/Material     D= Plug in and Take off Force
E= Metal Material       F=Material Thickness(mm)

A=JZ-002
B=Ø5×20
C=6A/250VAC
D=>2N
E=Phosphor bronze
F=0.3t




Fuse Clip for 5 X 20 mm Tube Fuse


Contact us if you need more details on 1 AMP Fuse Block. We are ready to answer your questions on packaging, logistics, certification or any other aspects about 2 AMP Fuse Block、3 AMP Fuse Block. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Fuse Clip
