Fb5y2702 High Sensitivity Rectangle Piezo Ceramic Element (FBELE)

Basic Info

Model No.:  FB5Y2702

Product Description

Model NO.: FB5Y2702 Signal Transmission: Wireless Alarm Sensor Type: Electric Alarm Transmission Mode: Wireless Receive Frequency: 229.95MHz Trademark: FBELE Origin: Ningbo Type: Anti-Theft Alarm Working Mode: Passive Working Principle: Electro-Optical Type Alarm Volume (within 1m): ≥90dB Size: 27*2 Specification: ROHS HS Code: 85318090 FB5Y2702 high sensitivity rectangle Piezo Ceramic element (FBELE)
Fb5y2702 High Sensitivity Rectangle Piezo Ceramic Element (FBELE)
No Part No Fr(KHz) Zr(ΩMAX) Cp(±30%nf) D d T t
1 FT-13x13T-9.5A2 9.5 ±1.0 100 56 13x13 13x13 0.48 0.15
2 FT-12T-5.8B1 5.8±0.3 500 12 12 9 0.12 0.05
3 FT-15T-6.0A1 6.0±0.5 350 12 15 11 0.23 0.1
4 FT-20T-6.5A1 6.5±0.2 350 12 20 15 0.43 0.2
5 FT-20T-3.6A1 3.6±0.3 350 24 20 14.7 0.24 0.1
6 FT-27T-4.0A1 4.0±0.3 350 20 27 20 0.43 0.2
7 FT-31T-4.0A1 4.0±0.5 300 45 31 20 0.24 0.1
8 FT-35G-3.2B1 3.1±0.2 200 26 35 25 0.55 0.3
9 FT-35T-2.8B1 2.8±0.5 200 24 35 25 0.55 0.3
10 FT-41T-1.0A1 2.8±0.2 300 66 41 25 0.22 0.1
11 FT-50T-2.9A1 2.5±0.5 500 30 50 25 0.43 0.2


FBELE Company, (Ningbo Best Group Co., Ltd. ) are Chinese leading manufacturer and distributor in electronic components. We can offer quality products in very competitive price for electronics components, as well as best service, in time delivery, small order acceptable, etc.

Contact us if you need more details on Piezo. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Speaker、Alarm. If these products fail to match your need, please contact us and we would like to provide relevant information.
